Modular Building Kits for Rapid Construction Projects, Temporary Housing, and Industrial Deployment Worldwide
Product Introduction
This YAGO flatpack container building is a modular, quick‑assembly temporary accommodation with superior thermal insulation, robust structure, easy transportation and fast installation. It provides safe, comfortable and reliable temporary living and working space for construction camps, mining sites, remote projects and field teams worldwideYAGO INDUSTRY.
Product Description
This flatpack container building is designed as a high‑efficiency modular temporary solution. Adopting standardized flat‑pack structure and full factory prefabrication, it ensures ultra‑convenient transportation and fast on‑site setup without complex construction. The 75mm fire‑rated fiberglass sandwich panels deliver outstanding thermal and sound insulation, keeping indoor warm in winter and cool in summer for comfortable living. The Q235 galvanized steel frame (zinc coating ≥80g/m²) with automatic powder coating guarantees stable structure, good wind resistance, strong corrosion protection and long service life. Its flat‑pack design supports frequent relocation between different sites, making it ideal for temporary camp use. With reliable waterproof and fireproof performance, it adapts to various outdoor environments and fully meets the temporary accommodation needs of global workforce campsYAGO INDUSTRYYAGO INDUSTRY.
Application Scenarios
- Construction site temporary camp and worker accommodation
- Mining, oilfield and remote engineering staff housing
- Field exploration and survey team temporary residence
- Emergency disaster relief and rescue temporary shelter
- Municipal project temporary duty and living quarters
- Overseas engineering project base housing
Specifications
| Fpatpack container SPECIFICATION SHEET |
| Project name: Flatpack Container 6.06*2.435*2.89m |
| A | Item | Specification |
| Steel Frame System System |
| 1 | Roof structure | Main roof frame: Q235 galvanized Steel profile, with Automatic Powder Coated paint Roof purlin: C Section Steel, galvanized. Q235B steel |
| 2 | Floor structure | Main floor frame: Q235 galvanized Steel profile,with Automatic Powder Coated paint Floor purlin:C Section Steel, galvanized. Q235B steel |
| 3 | Corner pillar | Q235 galvanized Steel profile, Galvanized with Automatic Powder Coated paint |
| Container roof System |
| 1 | Roof covering | Galvanized Powder Coated color painting steel Sheet. |
| 2 | Insulation | Fiber glass with aluminum foil |
| 3 | Ceiling board | Galvanized Powder Coated color painting steel Sheet. |
| Container floor System |
| 1 | PVC flooring | Vinly floor leather with glue |
| 2 | Floor board | 18mm fiber cement board |
| ContainerWall System |
| 1 | Wall panel | 50mm /75mm fireproof Mineral Rockwool Sandwich panel |
| 2 | Door | Insulated Steel Door |
| 3 | Window | PVC sliding window, double glass, with fly screen |
| Container Electrical System |
| 1 | Power distribution cabinet | Circuits with air-break switch, leakage protector, |
| 2 | Light | LED light, 24W |
| 3 | AC Socket | 16A universal, with socket box |
| 4 | Common Socket | 10A, Universal type, with socket box |
| 5 | Switch | 10A , with switch box |
| Plumbing system(Optional as per drawing) |
| 1 | washbasin | including the accessory |
| 2 | Closetool | including the accessory |
| 3 | shower | shower base, shower head, water mixture |
| 4 | Exhaust Fan | 6 Inch |
| 5 | water pipe | input and output water pipe |
| Stair case and Corridor. (Optional as per drawing) |
| 1 | Stair Case and Corridor | Fabricated with C channel steel, square tube, Round Steel, And checkered Steel Plate |
| Additional Traingle Roof on Top of Each Block. (Optional as per drawing) |
| 1 | Roof Structure | Fabricated with C section steel, Galvanized Q235 Steel. |
| 2 | Roof Covering | Corrugated Galvanized Powder Coated Roof Tile |
Advantages
- Excellent insulation: Warm in winter, cool in summer, quiet and comfortable
- Flatpack & portable: High transport efficiency, easy relocation, low shipping cost
- Quick setup: 2–3 workers finish assembly in 4–6 hours with basic tools
- Stable & durable: Galvanized + powder coated frame, windproof, anti‑corrosion
- Safe & reliable: Fireproof, waterproof, suitable for long‑term outdoor camp use
- Flexible layout: Single use or multi‑unit combination for large‑scale camp
FAQ
Q: What transportation methods are suitable? A: Flatpack design fits truck, container ship and other common transport, greatly saving cost.
Q: Can it be used in hot and cold regions? A: Yes, high‑efficiency insulation panels adapt to hot, cold and variable climates.
Q: Do we need professional tools for setup? A: No, simple conventional tools are enough; 2–3 workers can finish quickly with instructions.
Q: How is waterproof performance for long outdoor use? A: Integrated sealed waterproof structure performs well in rainy and humid environments.
Q: Can multiple units form a large camp? A: Yes, units can be connected horizontally or stacked to build a complete functional camp.
