Prefabricated Panel Housing Units for Temporary Accommodation, Mining Camps, Construction Sites, and Workforce Housing
Product Introduction
This Senior and Junior Management Building is a high‑end integrated prefabricated modular building designed for project management teams, offering comfortable office and accommodation space. It features a robust steel frame, fireproof rockwool panels, dry‑wet separated interior, and complete electrical and plumbing systems, providing a safe, quiet, and professional working and living environment for on-site management personnel.
Product Description
This management building adopts a Q235 galvanized square tube steel frame with powder‑coated painting for strong structural stability and corrosion resistance. The roof and wall systems use 50mm/75mm/100mm fireproof rockwool sandwich panels for excellent thermal insulation, sound insulation, and Class A fireproof performance. The interior is divided into dry and wet areas: dry rooms use gypsum board ceilings and vinyl floor leather, while wet rooms apply calcium silicate board ceilings and ceramic tiles for waterproofing and durability. It is equipped with insulated steel doors (850mm*2030mm) and PVC double‑glazed sliding windows with screens and blinds for lighting and privacy. The full electrical system includes LED lights, 10A/16A sockets, switches, and a power distribution cabinet with leakage protection. The complete plumbing system provides a toilet, washbasin, shower, and water pipes, enabling immediate use upon installation.
Application Scenarios
- Construction site senior & junior management offices and dormitories
- Project command center and on-site management headquarters
- Field operation management accommodation and reception rooms
- Overseas engineering project management building
- Temporary management and duty building for municipal engineering
Specifications
| Project name: Senior and Junior Management building |
| Item |
Specification |
| Main Steel Frame |
| Steel frame |
Square Tube Columns, Q235 Steel, Galvanized Steel with Powder coated painting |
| Steel structure roof |
C Section Steel, Q235 Steel, galvanized |
| Roof Purlin |
C Section Steel, Q235 Steel, galvanized |
| Wall purlin |
C Section Steel, Q235 Steel, galvanized |
| Cross bracing |
L40*3 |
| Anchor bolts |
M16, chemical Bolts |
| Ordinary bolt |
4.8S,Zincification, |
| Roofing and wall System |
| Roof Panel |
50mm/75mm/100mm Rockwool Sandwich panel |
| Wall Panel |
50mm/75mm/100mm Rockwool Sandwich panel |
| Ceiling & Flooring |
| Dry room Ceiling |
Gypsum board,with frame |
| Dry room Floor leather |
Vinyl floor leather |
| Wet room Ceiling02 |
Calcium silicate board Ceiling with Ceiling keel |
| Wet Ceramic tile |
Ceramic Tiles |
| Doors&windows |
| Door |
Insulated Steel door, 850mm*2030mm |
| Window |
PVC sliding window with double glas, with screen and window blind |
| Electric unit and sanitary facilities&plumbing |
| Electric cable |
With electrical cable for lighting, socket, AC and water heater system. |
| Lights |
LED light 220V,60HZ |
| Switch |
with junction box |
| Socket |
10A and 16A , with junction box |
| Power distribution cabinet |
box+switch+earth leakage protective device |
| Toilet |
including water valve |
| Washbasin |
including faucet, water pipe |
| Shower |
With shower head, water mixture, and shower base |
| Water pipe |
input and output water pipe |
Advantages
- Class A fireproof with rockwool panels, high safety for management use
- Excellent thermal and sound insulation for quiet working & living
- Dry‑wet separated design, hygienic and durable
- Complete electrical & plumbing, ready for immediate use
- Galvanized & powder‑coated frame, long service life
- Elegant interior with windows and blinds, suitable for management level
FAQ
Q: What fireproof grade does this management building achieve?
A: It reaches Class A fireproof grade by using rockwool sandwich panels.
Q: Can the interior be divided into office and bedroom areas?
A: Yes, the layout can be customized into separate office, lounge, and bedroom zones.
Q: Are the windows equipped with blinds?
A: Yes, PVC double‑glazed windows with built‑in screens and blinds for light control.
Q: Is this building suitable for long‑term on-site management use?
A: Yes, durable structure, good insulation, and complete facilities support long‑term use.
Q: Do we need to prepare additional electrical or plumbing materials on site?
A: No, all cables, sockets, lights, toilet, shower, and water pipes are pre‑configured.
