Dry Warm Temporary Construction Camp Insulated Windproof Quick Build Staff Living Quarters
Product Introduction
This temporary construction camp is a dry, warm, insulated, windproof, quick build staff living quarters designed for on-site staff. It provides a stable, cozy, and weatherproof living space with fast installation, excellent thermal insulation, and reliable windproof performance, ideal for construction sites and field projects.
Product Description
This dry warm temporary construction camp is a professional insulated windproof quick build staff living quarters solution. Adopting modular flatpack design and factory prefabrication, it can be assembled quickly on site to save time and labor costs. The high-performance insulated sandwich panels keep the interior dry and warm, effectively isolating cold and moisture. The reinforced structure delivers strong windproof performance, ensuring safety in harsh outdoor environments. The whole unit is waterproof, corrosion-resistant, and durable, creating a comfortable and healthy living environment for staff. It is widely used as temporary living quarters for construction sites, engineering teams, and remote projects.
Application Scenarios
- Construction site staff living quarters and dormitory
- Engineering project team temporary accommodation
- Municipal construction temporary staff housing
- Field construction and infrastructure camp
- Emergency rescue temporary living shelter
Specifications
-
| Project name: Flatpack Container 6.06*2.435*2.89m |
| A |
Item |
Specification |
| Steel Frame System System |
| 1 |
Roof structure |
Main roof frame: Q235 galvanized Steel profile, with Automatic Powder Coated paint Roof purlin: C Section Steel, galvanized. Q235B steel |
| 2 |
Floor structure |
Main floor frame: Q235 galvanized Steel profile,with Automatic Powder Coated paint Floor purlin:C Section Steel, galvanized. Q235B steel |
| 3 |
Corner pillar |
Q235 galvanized Steel profile, Galvanized with Automatic Powder Coated paint |
| Container roof System |
| 1 |
Roof covering |
Galvanized Powder Coated color painting steel Sheet. |
| 2 |
Insulation |
Fiber glass with aluminum foil |
| 3 |
Ceiling board |
Galvanized Powder Coated color painting steel Sheet. |
| Container floor System |
| 1 |
PVC flooring |
Vinly floor leather with glue |
| 2 |
Floor board |
18mm fiber cement board |
| ContainerWall System |
| 1 |
Wall panel |
50mm /75mm fireproof Mineral Rockwool Sandwich panel |
| 2 |
Door |
Insulated Steel Door |
| 3 |
Window |
PVC sliding window, double glass, with fly screen |
| Container Electrical System |
| 1 |
Power distribution cabinet |
Circuits with air-break switch, leakage protector, |
| 2 |
Light |
LED light, 24W |
| 3 |
AC Socket |
16A universal, with socket box |
| 4 |
Common Socket |
10A, Universal type, with socket box |
| 5 |
Switch |
10A , with switch box |
| Plumbing system(Optional as per drawing) |
| 1 |
washbasin |
including the accessory |
| 2 |
Closetool |
including the accessory |
| 3 |
shower |
shower base, shower head, water mixture |
| 4 |
Exhaust Fan |
6 Inch |
| 5 |
water pipe |
input and output water pipe |
| Stair case and Corridor. (Optional as per drawing) |
| 1 |
Stair Case and Corridor |
Fabricated with C channel steel, square tube, Round Steel, And checkered Steel Plate |
| Additional Traingle Roof on Top of Each Block. (Optional as per drawing) |
| 1 |
Roof Structure |
Fabricated with C section steel, Galvanized Q235 Steel. |
| 2 |
Roof Covering |
Corrugated Galvanized Powder Coated Roof Tile |
Advantages
- Dry & warm: Good insulation, anti-moisture, comfortable interior
- Insulated & energy-saving: Stable indoor temperature, low energy cost
- Strong windproof: Safe in strong wind and bad weather
- Quick build: Fast installation, short construction period
- Waterproof & durable: Long service life, low maintenance
- Flexible combination: Can build large-scale camp by multiple units
FAQ
Q: How does this living quarters keep dry in humid and rainy construction sites?
A: It uses fully sealed waterproof structure and moisture-proof panels to keep interior dry all the time.
Q: Can it keep warm effectively in low-temperature winter construction sites?
A: Yes, high-efficiency insulated panels provide excellent warm-keeping performance in cold weather.
Q: How many people can live in one standard staff living quarters unit?
A: One standard unit can accommodate 4–6 people with comfortable space for daily living.
Q: Do we need to make complex waterproof treatment on the roof?
A: No, the unit adopts factory-integrated waterproof design, no extra on-site waterproof work needed.
Q: Can this living quarters be moved and reused on new construction sites?
A: Yes, it can be quickly disassembled, transported, and reused many times without damage.
